Automatic Bare PCB Board Unloader & Stacker With Mitsubishi PLC + Kunlun Tongtai HMI For 2–8 PCS/Min Loading Speed And 350 × 300 Mm To 750 × 650 Mm PCB Size Range
  • name
  • name
  • name
  • name
  • name

Automatic Bare PCB Board Unloader & Stacker With Mitsubishi PLC + Kunlun Tongtai HMI For 2–8 PCS/Min Loading Speed And 350 × 300 Mm To 750 × 650 Mm PCB Size Range

Brand Name: HXT
Model Number: JXK-AF512/511
MOQ: 1 pcs
Price: 5000 -8000 USD
Packaging Details: Wodden box
Payment Terms: T/T
Detail Information
Product Description
Detail Information
Place of Origin:
China
Certification:
CE
Product Type:
Automatic Bare PCB Board Loader
Application:
PCB Manufacturing & Fabrication Production Lines
PCB Type:
Bare PCB, Rigid PCB, Single-Sided, Double-Sided & Multilayer PCB
PCB Size Range:
350 × 300 Mm To 750 × 650 Mm
PCB Thickness:
0.4–3.2 Mm
Loading Speed:
2–8 PCS/min
Control System:
Mitsubishi PLC + Kunlun Tongtai HMI
Safety & Automation Features:
Automatic Board Counting, Full-Rack Pre-Alarm, Fault Detection, Temporary Storage, Interlock Signal & Energy-Saving Mode
Supply Ability:
1000 pcs per month
Highlight:

Bare PCB Board Unloader & Stacker

,

Automatic PCB Unloader Stacker

,

Automatic Bare PCB Board Loader

Product Description

Automatic Bare PCB Board Unloader & Stacker With Mitsubishi PLC + Kunlun Tongtai HMI For 2–8 PCS/Min Loading Speed And 350 × 300 Mm To 750 × 650 Mm PCB Size Range

Automatic Bare PCB Board Loader for PCB Manufacturing & Fabrication Lines

Product Overview

The Automatic Bare PCB Board Loader is an automated PCB handling machine designed to load and transfer bare printed circuit boards (PCBs) from a stacked board supply into PCB manufacturing and fabrication processes.

It replaces manual board loading and provides stable, controlled and continuous PCB feeding between production stations. Depending on the line configuration, it can be integrated with conveyors, processing machines and other automated PCB fabrication equipment.

Unlike an SMT PCB Loader, which is primarily used to feed bare boards into SMT assembly equipment, this machine is positioned for PCB manufacturing, PCB fabrication and bare-board processing lines.

Equipment Dimensions (mm) L2400mm x W1300mm x H1650mm
Working Height (mm) 950mm ± 50mm
Working Width (mm) 870mm
Applicable Process Pre-treatment and cooling lines for developing, ENIG, HASL, etc.
Conveyor Speed ​​(m/min) 16/min
Standard Throughput (pcs/min) 28 panels
Applicable Board Thickness (mm) 0.6–3.2mm
Board Loading Capacity (mm) 50/75/100 panels
Max. Board Size (Optional) (mm) 730mm x 635mm
Min. Board Size (mm) 300mm x 300mm
Power Consumption (kW) Single-phase AC 220V, 0.2kW

Key Advantages

1. Automatic PCB Board Loading

Automatically feeds bare PCB panels into the production line, reducing manual board handling and improving production continuity.

2. Stable and Controlled Board Transfer

Provides consistent PCB positioning and transportation, helping maintain a stable production rhythm.

3. Reduced Manual Labor

Automation reduces repetitive manual loading operations and allows operators to focus on production monitoring and quality control.

4. Scratch-Protected PCB Handling

The board-handling mechanism is designed to minimize contact damage and protect PCB surfaces during loading and transfer.

5. Automatic Board Counting

The system can count processed boards automatically, making production quantity management easier.

6. Continuous Production

An automatic temporary-storage function can help maintain production continuity when the board rack is being changed.

7. Full-Rack Pre-Alarm

Provides an advance warning when the receiving/loading rack reaches its capacity, helping operators replace the rack before production interruption.

8. Automatic Fault Indication

The control system provides fault prompts to help operators identify abnormal conditions quickly.

9. PLC + HMI Control

A Mitsubishi PLC combined with Kunlun Tongtai HMI provides centralized control, parameter setting and straightforward machine operation.

10. Production-Line Interlocking

Interlock signals allow the loader to communicate with upstream/downstream equipment and coordinate automatic production.

11. Adjustable Operating Parameters

Parameters such as transfer speed and operating settings can be adjusted according to PCB size and production requirements.

12. Energy-Saving Operation

An energy-saving mode helps reduce unnecessary energy consumption during operation.

Applications

The Automatic Bare PCB Board Loader can be used in various PCB manufacturing and fabrication production lines, including:

PCB Manufacturing

  • Bare PCB Manufacturing
  • Printed Circuit Board Manufacturing
  • PCB Fabrication
  • PCB Production
  • Rigid PCB Manufacturing
  • Single-Sided PCB Manufacturing
  • Double-Sided PCB Manufacturing
  • Multilayer PCB Manufacturing
  • HDI PCB Manufacturing
  • High-Density PCB Production
  • Fine-Line PCB Manufacturing





Automatic Bare PCB Board Unloader & Stacker for PCB Manufacturing Fabrication Production Line
Automatic PCB Board Receiving & Stacking Machine for PCB Fabrication and Wet Process Line
Automatic Bare PCB Board Unloader Stacker for PCB Manufacturing, Pretreatment, Grinding, Etching and DES Production Line
Automatic Bare PCB Board Loader for PCB Manufacturing & Fabrication Lines
Automatic PCB Board Loading Machine for PCB Grinding, Pretreatment & Wet Process Lines
Automatic Bare PCB Board Loader for PCB Fabrication Production Line
