The Double-Sided High-Precision FPC/HDI Inline AOI Optical Inspection Machine is an automated optical inspection system designed for high-precision inspection of FPC (Flexible Printed Circuit), HDI (High-Density Interconnect), and other high-density PCB products during PCB manufacturing.

Its inline automation functions can identify different part numbers automatically, recognize board orientation, switch inspection programs automatically, and communicate with MES and automatic loading/unloading equipment.

1. Double-Sided Inspection
   1. Inspects the top and bottom sides of the FPC/HDI board.
   2. A double-sided configuration can reduce handling and avoid unnecessary board flipping. Some FPC AOI systems specifically use continuous double-sided inspection to reduce labor and improve productivity.
2. High-Precision Optical Inspection
   1. Uses high-resolution cameras, controlled lighting and image-processing algorithms to identify very small circuit-pattern defects.
   2. This is particularly important for high-density HDI and fine-line FPC products.
3. Designed for FPC & HDI
   1. Suitable for applications involving Flexible PCB (FPC), HDI PCB, fine-line PCB and other high-density boards.
   2. FPC and HDI inspection systems are designed around the smaller features and tighter tolerances found in these products.
4. Inline Production
   1. Can be connected directly to upstream and downstream PCB manufacturing equipment.
   2. This allows inspection to take place automatically without removing boards from the production line.
5. Reduced Manual Inspection
   1. Automated imaging reduces dependence on operators visually checking every board.
   2. AOI provides consistent inspection criteria rather than relying on individual operator judgment.
6. High-Speed Inspection
   1. Automated image acquisition allows continuous production inspection at speeds that are difficult to achieve with manual inspection.
   2. Double-sided simultaneous/continuous inspection can further reduce inspection cycle time.
7. Early Defect Detection
   1. Defects can be identified during the manufacturing process rather than being discovered later.
   2. This helps reduce downstream processing of defective boards and supports process correction.
8. Consistent & Repeatable Quality Control
   1. The machine applies programmed inspection criteria consistently across production.
   2. Inspection results can also be recorded for quality analysis and traceability when the system supports these functions.
9. Non-Contact Inspection
   1. Optical inspection examines the board using cameras rather than physically probing the circuit pattern, which is particularly useful for delicate materials such as FPC. AOI is fundamentally a non-contact visual inspection method.
10. Lower Risk of Handling Damage
    1. Automated/contact-free loading and unloading can reduce damage associated with manual handling, particularly for flexible materials.

This AOI machine is primarily used for PCB bare-board manufacturing and fabrication inspection, particularly where fine-line and high-density circuits require automated quality control.

Suitable for inspection of:

• Flexible Printed Circuits
• Flexible PCB
• FPC circuit patterns
• Fine-line FPC
• High-density flexible circuits
• Flexible electronic components

Typical applications include smartphones, wearable electronics, cameras, displays, automotive electronics and compact electronic devices.

Suitable for:

• HDI PCB
• High-density circuit boards
• Fine-line HDI boards
• Multilayer HDI boards
• Microvia-related circuit structures
• High-density interconnect patterns

It can inspect complex circuit patterns where conventional manual visual inspection is difficult.

The machine can inspect both sides of a PCB and is suitable for:

• Double-sided rigid PCB
• Double-sided FPC
• Multilayer PCB
• Fine-line PCB
• High-density PCB

Applicable to PCB fabrication processes involving:

• FR-4 bare copper boards
• CEM boards
• Copper-plated boards
• Aluminum-based PCBs
• Dry-film boards
• LED boards
• Etched circuit boards

The system can inspect circuit-pattern quality after PCB imaging, development, etching and related fabrication processes.
