Automatic Mounting Machine Cost Effective For SMT Production Lines PCB Component Mounter Assembly And Surface Mounting Repairing

Brand Name: RD
MOQ: 1
Price: $23,500
Detail Information
Product Description
Detail Information
Place of Origin:
China
Machine Type:
Pick And Place Machine
Product Name:
LED DOB Pick And Place Machine
Name:
Smt Pick And Place Machine
Function:
DOB Component Mounter
Usage:
SMT PCB Production Assembly Line
Marketing Type:
PCB Mounting Machine
Highlight:

70000CPH Placement Speed Pick and Place Machine

,

Automatic Nozzle Changing SMT Machine

,

Independent Camera Motor PCB Assembly Machine

Product Description
Automatic SMD Pick and Place Machine for LED DOB Circuit Board Assembly
Product Overview
High-performance surface mount component placement equipment designed for LED DOB lighting, small household appliances, control panels, point light sources, and other electronic manufacturing applications.
Automatic Mounting Machine Cost Effective For SMT Production Lines PCB Component Mounter Assembly And Surface Mounting Repairing 0
Key Features

Equipped with a suction nozzle exchange station, achieving simultaneous installation of single machines with the same size and material. Standard tray material station is equipped, and the woven tray material can be installed simultaneously. Each group of mounting heads independently controls the rotation angle, resulting in higher mounting efficiency. The highest efficiency of DOB component installation can reach 18000 chips/h. Suitable for: DOB light source, small household appliances, control panel, point light source, etc. Equipped with suction nozzle warehouse exchange station, large and small materials can be installed on a single machine; Standard tray material station is equipped, and the braided material can be pasted at the same time; 9 sets of individual gigabit network interface industrial flight error photo correction system.

Technical Specifications
Model NoRD-8MFRD-12MFRD-8MFLRD-12MFL
Number of mounting heads8 heads12 heads8 heads12 heads
Feeder Station26 stations35 stations26 stations35 stations
Optimal placement speed35000 chips/h55000 chips/h35000 chips/h55000 chips/h
Maximum mounting plate size800mm×500mm (segmented patch, each segment  can be pasted with 400mm)1200mm×500mm (segmented patch, each segment  can be pasted with 600mm)
Machine weightApproximately 1350KGApproximately 1600KG
External dimensions1350mm long ×1350mm wide×1500mm high1800mm long×1500mm wide×1500mm high
Height of Attachable Components＜22mm
Pallet material1～3 standard pallets
Suction nozzle libraryAutomatic exchange nozzle library 24 stations (RD-12MF/RD-12MFL models have 36 stations)
Substrate transfer methodThree section track automatic transmission
Machine SystemIndependently developed operating system
Positioning methodVisual automatic MARK points
Correction of suction error by flying swatterEach nozzle corresponds independently to a 1 megapixel flying camera for visual correction
Programming methodVisual camera positioning programming/Excel format file coordinate import
Input power/voltageAC220V/50HZ (operating power approximately 2KW/H)
Mountable componentsAbove 0402 lamp beads, resistors, capacitors, ICs, terminals, electrolyzers, inductors, diodes, QFPs, etc.

Advanced Vision System
Each placement head features an independent camera motor with dedicated lens/zoom components for on-the-fly alignment vision processing.
Parallel Vision Processing
All 12 placement heads simultaneously capture images and perform recognition calculations while in motion, eliminating waiting and queuing times.
True On-the-Fly Alignment
Component recognition is 100% synchronized with placement head movement. As heads move from pick-up to placement positions, built-in cameras complete component recognition, positioning, and angle calculations, achieving zero visual waiting time.
Automatic Nozzle Changing
Core technology enabling higher efficiency, intelligence, and flexibility in SMT production lines.
Production Efficiency Benefits
  • Fast nozzle changing within seconds without manual intervention
  • Continuous production supporting rapid product switching
  • Optimized placement cycles with automatic nozzle matching
Placement Head Configurations
8 Placement Head: Independently controlled rotation angle, 50,000 chips/hour
10 Placement Head: Independently controlled rotation angle, 60,000 chips/hour
Application Scope
Ideal for large, thick PCBs with high component density, including capacitors, resistors, inductors, fuses, terminal blocks, and large connectors. Primarily used in LED DOB lighting, LED drivers, and industrial control board production.
