Fully Automatic SMT Chip Mounter with 70000CPH Placement Speed and 12 Spindles for PCB Assembly

Brand Name:	RD
MOQ:	1
Price:	$22,700

Detail Information

Product Description

Detail Information

Place of Origin:

China

Machine Type:

Pick And Place Machine

Product Name:

Pick And Place Machine

Type:

Fully Automatic

Application:

SMT PCB Assembly Production Line

Name:

LED Pick And Place Machine

Usage:

SMT Machines PCB Assembly

Marketing Type:

Linear LED Light Source Pick And Place Machine

Highlight:

70000CPH Placement Speed Pick and Place Machine

12 Spindles SMT Chip Mounter

Fully Automatic PCB Assembly Machine

Product Description

Chip Mounter SMD Placer Robot for Electronics SMT PCB Assembly

Advanced automated placement system designed for high-efficiency electronics manufacturing production lines.

Key Features

Independent rotation angle control for each mounting head
Dedicated 1-megapixel flying camera for each nozzle
Handles PCB boards up to 1200mm in single operation
Parallel vision processing for maximum efficiency
True on-the-fly alignment with zero visual waiting time

Applications

Ideal for modules, fluorescent tubes, soft light strips, outdoor lights, ceiling lights, flat panel lights, and various electronic assemblies.

Technical Specifications

Parameter	RD-ZT8VS	RD-ZT10VS	RD-ZT12VS
Number of Mounting Heads	8 heads	10 heads	12 heads
Feeder Station	30 stations	27 stations	30 stations
Optimal Placement Speed	50,000 chips/h	60,000 chips/h	70,000 chips/h
Machine Weight	Approximately 1600KG
Component Height Capacity	<8mm
Maximum PCB Size	1200mm × 500mm
External Dimensions	2300mm × 1350mm × 1500mm
Substrate Transfer	Single track automatic transmission
Operating System	Independently developed system
Positioning Method	Visual automatic MARK points
Programming Method	Visual camera positioning / Excel coordinate import
Power Requirements	AC220V / 50HZ (approx. 2KW/H)
Mountable Components	Beads, resistors, capacitors, ICs, terminals, diodes (0603 and above)

Advanced Vision System Technology

Independent Camera Motors: Each placement head features its own independent camera motor and lens/zoom component, representing the ultimate configuration for high-end precision electronics manufacturing.

This revolutionary hardware parallelization design resolves the fundamental efficiency vs. precision conflict that cannot be addressed at software level.

Parallel Vision Processing: All 12 placement heads simultaneously capture images and perform component recognition calculations while in motion - no waiting, no queuing.

True On-the-Fly Alignment

Component recognition is 100% synchronized with placement head movement. As the head moves from pick-up to PCB placement position, its built-in camera completes component recognition, positioning, and angle calculation en route. Upon reaching the target point, placement occurs immediately with zero visual waiting time.

Model Variations

8 Placement Head: Independent rotation angle control, 50,000 chips/hour

10 Placement Head: Independent rotation angle control, 60,000 chips/hour

12 Placement Head (Optional): Independent rotation angle control, 70,000 chips/hour

Product Images

Certifications

Application Examples

Frequently Asked Questions

Q1. This is the first time I use this kind of machine, is it easy to operate?

A: Comprehensive English manual and guide video provided. We can also send engineers to your factory for installation training. Additional support available via email, Skype, phone, or online service.

Q2: Do you offer guarantee for the products?

A: Yes, we offer 1-year warranty with lifetime after-sales support.

Q3. If machine have any problem after I receive it, how can I do?

A: Free replacement parts provided during warranty period. Shipping costs covered by us for parts under 0.5KG; customer responsible for shipping costs above 0.5KG.

Q4. How to proceed an order for SMT Loader machine?

A: 1. Specify your requirements or application. 2. Receive customized quotation. 3. Confirm details and place deposit. 4. Production begins.

Q5. MOQ?

A: Minimum order quantity is 1 set. Mixed orders welcome.

Q6. How do you ship the goods and how long does it take to arrive?

A: Shipping by sea with CIF or DDP options. Delivery time: 25-35 days.

Q7. What about the lead time?

A: Stock availability: 3-7 days. Mass production: 15-25 working days.

Q8. What is your payment method?

A: 30% advance TT payment, 70% TT payment when goods are ready for shipment.
