30W 50W 60W CO2 Laser Engraver for Non Metal Cutting with High Precision Marking on Wood Acrylic Leather Fabric

Brand Name:	HXT
Model Number:	HXT-20W
MOQ:	1
Price:	1300
Packaging Details:	Vacuum packing plus wooden box packing
Payment Terms:	T/T

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Name:

Laser Marking Machine

Supplier:

Model Number:

20w 30w 50w 70w 100w

Function:

CO2 Laser Engraving Machine

Usage:

Fiber Laser Marking Machine 20w 30w 50w 70w 100w

Field Lens:

0/110/150/180mm Imported Wavelength Full Range Of Lens Sets

Power:

220V/50HZ 320W

Warranty:

1 Year

Delivery Term:

7-15 Days

Supply Ability:

The production capacity is 30 units a month

Highlight:

30W CO2 laser engraver for wood

50W desktop laser cutter for acrylic

60W CO2 laser marker for leather

Product Description

Desktop CO2 Laser Engraver 30W 50W 60W

Professional laser cutting and marking system for non-metal materials including wood, acrylic, leather, and fabric. Ideal for commercial signage, advertising, awards, trophy manufacturing, and industrial applications.

Product Overview

Fiber laser marking machine uses laser beams to create permanent marks on various material surfaces through evaporation, chemical changes, or material removal. This compact, air-cooled system delivers exceptional precision for patterns, characters, barcodes, and graphics.

Key Features

Stable laser power output with superior spot quality
High-speed marking - 2-3 times faster than traditional models
Operating system independent with fully enclosed optical path
Environmentally friendly - no pollution, noise, or consumables
Ultra-high precision with resolution up to 2540dpi
Compact design with low power consumption
Excellent beam quality for ultra-fine marking applications
High-performance UV laser with precision scanning galvanometer
Minimal maintenance requirements and operating costs

Software Capabilities

Supports BMP, JPG, DXF, PLT, AI, and other file formats
Automatic generation of serial numbers, dates, barcodes, and QR codes
Flight marking and rotary marking support
Large-area XY platform automatic segmentation marking

Technical Specifications

Device Configuration

Component	Specification
Laser	Raycus 20W/30W/50W Q-switched fiber optic pulse laser transmitter
Vibrating Head	Jinhai Chuang German technology high-speed digital galvanometer
Control Card	Fiber optic dedicated card (static and dynamic common)
Computer	Industrial computer with monitor
Field Lens	70/110/150/180mm imported wavelength full range lens sets
Software System	Laser information marking system

Technical Parameters

Parameter	Unit	Value
Power	W	20
Wavelength	nm	1064
Minimum Character	mm	0.1
Minimum Line Width	mm	0.01
Beam Quality (M2)	M2	<1.5
Marking Range	mm	70/110/150/180 (optional)
Cooling Method	-	Air cooled
Total Power	W	<500
Total Weight	kg	Approximately 70

Applications & Industries

This versatile laser marking system serves multiple industries and materials with precision and reliability.

Target Industries

Mobile phone buttons and plastic light-transmitting components
Electronic components and integrated circuits (IC)
Electrical appliances and communication products
Sanitary ware, tool accessories, and cutting instruments
Eyewear, timepieces, and jewelry manufacturing
Automotive parts and components
Luggage decoration and hardware accessories
Cooking utensils and stainless steel products

Compatible Materials

All metals including rare metals
Engineering plastics and electroplating materials
Coating materials and spray paint surfaces
Plastic rubber and epoxy resin compounds
Ceramics and various industrial materials

Custom solutions available including software development, automated loading/unloading systems, database integration, and connectivity with MES/ERP systems.
