Semiconductor Production Line Led strip light Assembly Machine Smt Pick and Place Machine for LED Rope Light

Advantages of wireless mounting machine


YSD-W200 LED wireless single-rail pick and place machine dual-module group take group placement, left and right a, B module alternative placement lamp beads, standard with 68 sets of suckers.
The actual placement speed can reach 150,000-250,000 CPH/hour
For FPCB Board LED strip length: 5 meters, 25 meters, 50 meters to infinite length (within 1 meter of a unit) width 230-270 mm.
Mounting parts range 1206 and above and 0805,0603,2835,3014,4014,3528,5050,5730 LED tape mounting accuracy ± 0.04 mm Chip.
Number of feeders available 64(8 mm feeders)
2 megapixel CCD with one lens for Mark positioning and 2 megapixel CCD with four lenses for nozzle and FITA adjustment.
YSD-W200 placement machine using an original structure, nozzle spacing can be adjusted, nozzle angle 360 degrees rotation. With high applicability, can adapt to a variety of LED Rope Lights with the mounting needs.


Semiconductor Production Line Led strip light Assembly Machine Smt Pick and Place Machine for LED Rope Light


Applicable


LED lamp with high voltage lamp with (220V) low voltage lamp with (12V/24V) single panel, double panel.
Usually used for LED chip density optional (such as 60 LED, 120 LED, 240 LED) , Power Common 6.8 W/m, 10W/m 24W/m.
Low voltage constant current lamp with long distance stable brightness, input voltage range 22-40v


Semiconductor Production Line Led strip light Assembly Machine Smt Pick and Place Machine for LED Rope Light
