Fully Automatic PCB V-CUT Machine – High Precision V-Groove Separator for LED Strip & Aluminum Board

Brand Name: HXT
Model Number: MDV-380B
MOQ: 1 pcs
Price: 5300 USD
Packaging Details: Wodden box
Payment Terms: T/T
Detail Information
Product Description
Detail Information
Place of Origin:
China
Certification:
CE
Machine Dimension:
1850mm*780mm*1100mm
Maximum Board Width:
330mm
Minimum Board Width:
150mm
Plate Feed Speed:
6-10 M/min (adjustable)
Machine Weight:
300KG
Maximum Plate Length:
1250mm
Supply Ability:
1000 pcs per month
Highlight:

High Precision PCB V-CUT Machine

,

LED Strip PCB V-CUT Machine

,

Fully Automatic PCB V-CUT Machine

Product Description

Auto Feeding PCB Depaneling Machine – V-Cut Router with Dust Collection for Aluminum PCB

Industrial PCB Strip Slitter – Fully Automatic V-Score Depanelizing Router with Precision Control

Programmable Bidirectional PCB V-CUT Machine – High Accuracy Separator for Multi-Panel Boards

Definition

An Automatic PCB V-CUT Machine (also known as a V-groove depaneling machine or routing-type depanelizer) is an automated device specifically designed for SMT (Surface Mount Technology) production lines. Its core function is to accurately and efficiently separate multi-board panels into individual circuit board units by mechanically cutting along the pre-scored V-shaped grooves (V-cut / V-Score) on the PCB panel.

Description

This equipment is primarily used to replace traditional manual hand-breaking methods. The typical workflow is as follows: the operator places the PCB panel with V-grooves into the machine, where a conveying mechanism feeds it into the cutting area. Subsequently, high-speed rotating circular blades move precisely along the centerline of the pre-set V-grooves to perform the cutting. By precisely controlling the distance between the upper and lower blades, the machine cleanly separates the PCB along the V-groove.
The key to the entire process is that the PCB remains stationary while the blades move to perform the cut, ensuring extremely high cutting consistency and stability. Automated operation not only achieves significantly higher efficiency than manual methods but also effectively prevents PCB damage, solder joint cracking, and component damage caused by uneven human force.

Specification
Machine NameAuto PCB V-CUT MachineAuto PCB Strip Cutting MachineSteering Bidirectional Conveying PCB V-CUT Machine
Machine ModelMDV-380BMDV-380CMDV-480+380
Minimum Plate Length400mm300mm140mm
Maximum Plate Length1250mm1250mm400mm
Minimum Board Width150mm120mm120mm
Maximum Board Width330mm330mm300mm
Plate Feed Speed6-10 m/min (adjustable)1-2.5 m/min (adjustable)/
Withstand The Weight Of The Board300KG250KG/
Total Depth Of Feed Chute380mm350mm/
Feed Chute Stroke Depth350mm Adjustable for long and short boards, speed adjustable330mm/
Water-absorbing cotton customizationOptional water-absorbing cotton version available
Loading and Unloading MethodAutomatic loading and unloadingAutomatic loading and unloadingManual Loading
Operation SystemPLC system for easy operation
Power SupplyThree-phase five-wire AC380V 5.0KWThree-phase five-wire AC380V 4.5KW
Air Supply0.5MPA-0.7MPA/
Machine Dimension(L*W*H)1400mm*2900mm*1700mm1400mm*3100mm*1700mm2000mm*1350mm*1100mm
Machine Weight640KG640KG563KG
Machine NameSemi-Automatic V-CUT Machine
Machine ModelMDV-380AMDV-480AMDV-580A
Minimum Plate Length150mm
Maximum Plate Length150mm-No Limit
Maximum Board Width330mm430mm535mm
Plate Feed Speed0-13m/min (adjustable)
Water-absorbing cotton customizationOptional water-absorbing cotton version available
Loading and Unloading MethodManual Loading
Operation SystemButton switch panel operation
Power SupplyThree-phase five-wire AC380V 3.0KW
Machine Dimension(L*W*H)1850mm*780mm*1100mm1850mm*880mm*1100mm1850mm*980mm*1100mm
Machine Weight300KG350KG380KG
Key Features

  • High Cutting Precision & Consistency: Cuts precisely along the centerline of the pre-set V-grooves, ensuring that separated individual boards have flat, smooth, and consistently sized edges.

  • Low-Stress Depaneling: Through optimized mechanical design, physical stress generated during cutting is significantly reduced, effectively preventing PCB laminate cracking, solder joint fractures, and damage to precision components such as BGAs and ceramic capacitors.

  • Wide Material & Board Thickness Adaptability: Can handle various board materials, including FR4 fiberglass, aluminum substrate (MCPCB), copper substrate, and more. Supported PCB thickness typically ranges from 0.2mm to 3.2mm.

  • Robust Automation & Programmability: Utilizes microcomputer or PLC (Programmable Logic Controller) control, capable of storing up to 100 different product cutting parameters for rapid changeovers. Cutting speed is adjustable, with some high-end models achieving speeds up to 40 meters per minute.

  • High Durability & Low Maintenance: The core blades are typically manufactured from high-quality materials such as imported high-speed steel or SKD11 tool steel, offering excellent wear resistance. Blades can be re-ground and reused 7–10 times after wear, significantly extending service life.

  • Comprehensive Safety Protection: Equipment is usually equipped with photoelectric safety sensors and protective guarding, capable of instantly braking the blades during operation, ensuring comprehensive operator safety.

Application

Leveraging its high efficiency and precision, the Automatic PCB V-CUT Machine is widely used across various electronics manufacturing sectors, particularly in scenarios requiring high-volume, regular-shaped PCB depaneling.

  • Consumer Electronics: PCB depaneling for smartphones, tablets, laptops, and more.

  • LED Lighting & Displays: Precision cutting of LED strips, LED lighting driver boards, and COB light source boards.

  • Automotive Electronics: Separation of circuit boards for vehicle control units, sensors, and more.

  • Industrial & Power Electronics: Bulk depaneling of power supply modules, industrial control boards, and home appliance control boards.

  • Telecommunications & Networking: Processing of circuit boards for routers, base stations, and other communication equipment.

  • Medical & Semiconductor: Separation of precision circuit boards for medical devices and semiconductor-related applications.
