Automatic Selective Soldering Machine with Flux Spray and Vision Scanning for PCB Wave Soldering Controlled by Industrial Computer

Brand Name:	HXT
MOQ:	1
Price:	CN¥31,358.70

Detail Information

Product Description

Detail Information

Place of Origin:

Guangdong, China

Weight:

60 KG

Voltage:

220 V, 110 V, 380 V, 240 V, 440 V

Frame Dimensions:

700*620*77.5 Mm

Frame Travel:

400*400*100 Mm

Fixture Dimensions:

250*300 Mm

Max Soldering Size:

260*190 Mm

Solder Pot Capacity:

5 Kg

Solder Pot Dimensions:

265*120*180 Mm

Heating Power:

1500 W

Rated Power:

500 W

Operating Voltage:

220 V

Control Method:

Motion Control System + Computer Programming

Programming Method:

Vision Scanning And Input, Computer Programming

Flux Spraying:

Precision Spraying With Line Spray Valve

Nitrogen Requirement:

99.999%, 1 Cubic Meter Per Hour

Highlight:

Automatic Flux Spray Selective Soldering Machine

Vision Scanning Module PCB Soldering Machine

Industrial Computer Control Wave Soldering Machine

Product Description

Automatic Selective Soldering Machine

Advanced flux spray and preheating system for SMT/DIP/THT/PCB wave soldering applications

Product Overview

This industrial-grade selective soldering machine features a comprehensive five-component design including frame, wave soldering furnace, flux spray valve module, vision scanning module, and industrial computer with monitor.

Key Advantages

Industrial computer control with self-developed programming system
High-definition camera vision scanning for rapid PCB data import
Intuitive programming via point and line input methods
Faster soldering speeds compared to manual operations
Uniform, full solder joints with consistent quality output
Easy to learn and simple to operate

Technical Specifications

Parameter	Specification
Model Number	PCH20
Frame Dimensions (L x W x H)	700 × 620 × 77.5 mm
Frame Travel	400 × 400 × 100 mm
Universal Fixture Dimensions	250 × 300 mm
Maximum Soldering Size	260 × 190 mm
Solder Pot Capacity	5 kg
Solder Pot Dimensions (with Nozzle)	265 × 120 × 180 mm
Heating Power	1500 W
Rated Power	500 W
Operating Voltage	220 V
Control Method	Motion control system + computer programming
Programming Method	Vision scanning and input, computer programming
Flux Spraying	Precision spraying with line spray valve
Nitrogen Requirement	Nitrogen content 99.999%, 1 cubic meter per hour
Weight	60 kg

Machine Details

KRZH Nitrogen Generator

Integrated 1-to-1 nitrogen generation system featuring stable performance, intelligent operation, energy efficiency, and quality assurance.

Generator Features

One-touch start operation with high intelligence
Silicone oil pressure gauge for accurate gas volume display
Precision filter equipped nitrogen outlet
Built-in large-capacity tank with dual-tank AB filling
Professional compression device to reduce dusting
Improves welding quality and aesthetics

Nitrogen Generator Specifications

Parameter	Specification
Model	YS49-1
Power Supply	AC220V 50HZ
Inlet Pressure	0.6-0.8 MPa
Power	20W
Nitrogen Pressure	0.1-0.65 MPa (Adjustable)
Laser Gas Capacity	1 laser welder
Maximum Pressure	0.8 MPa
Nitrogen Temperature	≤10-25°C
Minimum Purity	99.99%
Nitrogen Dew Point	≤-40°C
Rated Purity	99.995%
Operating Environment	-15°C-55°C
Maximum Purity	99.999%
Dust Content	≤0.01PPM
Nitrogen Oil Content	≤0.002PPM
System Pressure Differential	≤0.15 MPa
Purity Indicator	Not Included (Standard) / Optional
Dimensions	700 × 450 × 880 mm
Nitrogen Output	1.2 Nm³/h
Weight	75 kg

Purity vs Output Capacity

99% Purity: 3 Nm³/h Output
99.9% Purity: 2 Nm³/h Output
99.99% Purity: 1.2 Nm³/h Output
99.999% Purity: 1 Nm³/h Output

Quality Certifications

Application Examples

The core value of selective wave soldering lies in its precision and selectivity. This technology addresses critical soldering challenges including complex through-hole components requiring high reliability, double-sided mixed-technology PCB assembly, shadowing effect mitigation, nitrogen-protected soldering environments, and high-reliability mixed-technology applications. It offers unparalleled advantages in quality control, operational flexibility, and thermal management, making it essential for high-end electronics manufacturing with stringent quality requirements and premium product value.

Additional Applications

Frequently Asked Questions

Q1. This is the first time I use this kind of machine, is it easy to operate?

A: Comprehensive English manual and instructional video provided. We offer engineer support for factory installation and training. Additional assistance available via email, Skype, phone, or online service.

Q2: Do you offer guarantee for the products?

A: Yes, we provide 1-year warranty with lifetime after-sales support.

Q3. If machine have any problem after I receive it, how can I do?

A: Free replacement parts during warranty period. Shipping costs covered by us for parts under 0.5kg; customer responsible for shipping costs over 0.5kg.

Q4. How to proceed an order for SMT Loader machine?

A: Order process: 1) Specify requirements or application, 2) Receive quotation, 3) Confirm details and place deposit, 4) Production arrangement.

Q5. MOQ?

A: Minimum order quantity is 1 set. Mixed orders accepted.

Q6. How do you ship the goods and how long does it take to arrive?

A: Shipping via sea transport, CIF or DDP terms. Delivery timeframe: 25-35 days.

Q7. What about the lead time?

A: Stock availability: 3-7 days. Mass production: 15-25 working days.

Q8. What is your payment method?

A: 30% advance TT payment, 70% TT payment upon goods readiness for shipment.

Tags:
