Automatic SMT PCB NG OK Unloader Machine With Magazine Loader Buffer Stocker For Production Line
  • name
  • name
  • name
  • name
  • name
  • name
  • name

Automatic SMT PCB NG OK Unloader Machine With Magazine Loader Buffer Stocker For Production Line

Brand Name: HXT
MOQ: 1
Price: $3,600
Detail Information
Product Description
Detail Information
Place of Origin:
Guangdong, China
Dimensions:
1500mm×1500mm×1300mm
Power Supply:
220V AC, Single Phase
Machine Type:
NGOK Unloader Machine
Application:
SMT PCB Assembly Production Line
Product Name:
SMT Unloader
Function:
Magazine Loader Buffer Stocker
Highlight:

200 KG Weight SMT Unloader

,

1500mm×1500mm×1300mm Dimensions PCB Loader and Unloader

,

50pcs Storage Capacity NGOK Unloader Machine

Product Description

SMT PCB NG OK Buffer Conveyor Unloader Machine With Vacuum Loader Magazine System Production Line
Automatic PCB Magazine Loader Unloader NGOK Buffer Stocker Machine For SMT Pick And Place Equipment
Factory Direct SMT NGOK Unloader Machine With PLC Control PCB Buffer Conveyor LED Production Line
Smart Customized NGOK Unloader Buffer Machine With Cooling System Easy Operation PCB Handling Equipment
Original SMT PCB Magazine Loader Unloader NGOK Buffer Stocker Machine For Pick And Place Assembly
Automatic NG OK Unloader Conveyor Machine With Chain Transmission Electronic Equipment Production Line
High Efficiency SMT PCB NGOK Buffer Unloader Machine With Motor PLC Control Industrial Assembly Line


Strip Die Bonder-Dual Dispensing

● Appearance structure: sheet metal structure and aluminum profile into the frame, the surface is sprayed, and the color is corrugated white.
● Microcomputer PLC control system, stable and reliable.
● Touch screen display operation, with automatic fault diagnosis function, convenient man-machine dialogue.
● Multiple sound and light and touch screen alarm function.
● The lifting step of the rack can be set according to the thickness of the PCB.
● With automatic counting function, it is convenient for production statistics.
● Humanized design ensures that the PCB board will not be broken, improving output capacity
● The lower connection receives the PCB board and uses the motor to send the board to the material frame
● Using stepping motor to push the plate, the strength can be adjusted, and the speed can be set on the touch screen.
● The push plate device adopts two limit positions to protect the PCB board
● Good boards and bad boards can be separated from top to bottom, and the number of layers can be set.
● Double line numbers distinguish between NGOK



Product specification

Device model

250

330

390

Applicable frame size

355*320*563mm

460*400*563mm

535*460*563mm

PCB board size (MM)

350*(50-250)

450*(50-330)

530*(50-390)

PCB thickness

0.6-3.0mm

0.6-3.0mm

0.6-3.0mm

transfer speed

10S/PCS

10S/PCS

10S/PCS

Transport height

900±20mm

900±20mm

900±20mm

delivery weight

60-2000g

60-2000g

60-2000g

Dimensions (L*W*H)

1500x1500x1300mm

1900x1600x1250mm

2100x1750x1250mm

body weight

About 200kg

380KG

420KG

Starting power/no-load power

200W

250W

300W

Power supply and

negative charge

220V AC, single phase

Step selection

1~5 steps (10mmstep distance)

Supply air source

4-6kg

Fixed side

Front fixation (rear fixation can be customized)

Transmission direction

Left to right (can be customized from right to left)

Number of storage boxes

2pcs

Conveying direction

L-R/R-L optional

Withstand voltage

AC terminal to ground 1500VAC, 1 minute

Use environment

Environment free of corrosive gas and dust

Anti-jamming

Voltage noise: 1000Vp-p, wave width 1us, 1 minute

Transfer and connection

push PCB board

Using stepping motor (42*48)

Parallel transfer

sub-NGOK PCB

Adopt 86 high-precision stepping motor

Translation load

transmission device

Imported steel wire synchronous belt

NG line number

Automatically move to the NG storage frame

(the storage frame can be automatically entered and exited)

OK line number

Automatically enter the OK box through the translation platform




Applications:

For SMT PCB board production assembling full line machines.
